The Roof Block TRB-01 QUICK RoofTop Block, 2 in Pipe, 350 lb Load, HDPE
Part #7056
MFG #TRB-01
The Roof Block TRB-01 QUICK RoofTop Block, 2 in Pipe, 350 lb Load, HDPE
Part #7056
MFG #TRB-01
Sign In to See Your Price
The Roof Block TRB-01 QUICK RoofTop Block, 2 in Pipe, 350 lb Load, HDPE
Part #7056
MFG #TRB-01
- Item Features
- Attributes
- Documents
Item Features
- 1 in thick , 30 PSI Owen Corning Foamular 300 Polystyrene rigid insulation.
- High Density Polyethylene Black UV stabilized.100 to .150 thickness.
- Max load per Block. Single point load of 250Ibs/ 113 kgs. Dual point or StrutMounted Load 350 Ibs/158 kgs. Apply TRB-STR 10" slotted steel strut channel under heavy loads over 250 Ibs.
- Space Block approximately every 6 to 7 feet along and if possible on all pipe couplings, elbows and unions.
- Screw holes for #10 sheet metal screws. Block supplied with 3/4 in universal clamping strap for up to 2 in pipe. Top surface easily adapts to all types of piping clamps, clips, slotted strut and 3/8 in to 1/2 in threaded rod. All pipe fastening and adjustments done from bottom side only.
- 1-1/2 in High Density Polyethylene top height extender, 10 in slotted steel strut, 12 in threaded, 12 in threaded rod, pipe rollers.
- 9 in Overall length.
Attributes
ColorBlack
Dimensions4-1/2 in H x 8-1/2 in W
Load Capacity350 lb
MaterialHDPE
Mounting TypeSaddle
Pipe Size2 in
Temperature Rating200 deg F
Thickness.100 to .150 in
